TG15MDASQ

Manufacturer Brand

Abbott Workholding Products logo

MFG Item Number: TG15MDASQ

Strike SKU: TG15MDASQ-MSC-04226684

Product overview 2-1/2" OAW, 3" OAH, 6-1/2" OAL, 3" Between Mount Holes, 0.625" Fastener

Out of Stock
View full details

Product overview

2-1/2" OAW, 3" OAH, 6-1/2" OAL, 3" Between Mount Holes, 0.625" Fastener, Aluminum

Manufacturer
Abbott Workholding Products
Part number
TG15MDASQ
Condition
New

Review the specifications below to confirm compatibility with your application.

Specifications

Jaw Shape Square
Jaw Interface Type Tongue & Groove
Material Aluminum
Maximum Compatible Chuck Diameter (Decimal Inch) 18.0000
Minimum Compatible Chuck Diameter (mm) 381.00
Minimum Compatible Chuck Diameter (Decimal Inch) 15.0000
Distance Between Mount Hole Centers (Decimal Inch) 3.0000
Distance Between Mount Hole Centers (mm) 76.20
Tongue Width (Decimal Inch) 0.7500
Tongue Length (Decimal Inch) 0.7500
Tongue Width (mm) 19.10
Fastener Size (Decimal Inch) 0.6250
Slot Width 12.70
Slot Width (Decimal Inch) 0.5000
Groove Width (mm) 12.70
Groove Width (D) (Decimal Inch) 0.5000
Overall Height (Decimal Inch) 3.0000
Overall Height (mm) 76.20
Overall Length (Inch) 6-1/2
Overall Length (Decimal Inch) 6.5000
Material Grade 6061-T6
Overall Width/Diameter (Inch) 2-1/2
Overall Width/Diameter (Decimal Inch) 2.5000
Number Of Jaws 3
UNSPSC Code 31162902
Country of Origin UNITED STATES
Mfr# TG15MDASQ

Please confirm the manufacturer part number and specifications before ordering.

Strike knowledgebase

  • Selection guidesBrowse buying guides that help narrow the right industrial part for the application
  • Technical referenceUse reference pages, charts, and definitions to confirm fit, ratings, and application details
  • Troubleshooting resourcesBrowse problem-solving guides before deciding the product itself needs replacement

Product Sourcing Notes

TG15MDASQ is listed for Abbott Workholding Products and described as Soft Lathe Chuck Jaw: Tongue & Groove in Lathe Chucks, Centers, Rests & Accessories . Use this page to confirm the part number, availability, product family, and application details before requesting a quote.

  • Manufacturer part number: TG15MDASQ
  • Strike SKU: TG15MDASQ-MSC-04226684
  • Manufacturer: Abbott Workholding Products
  • Catalog family: Lathe Chucks, Centers, Rests & Accessories
  • Availability: request a quote
